Motherboard Manual
40
Russian
Спецификации
Поддержка
центрального
процессора
AMD E-350D (A68I-350 DELUXE/ A68I-350 DELUXE R2.0) / AMD C-60 (A68I-C60)
Набор микросхем AMD A68 FCH
Память
Поддерживает Одноканальный DDR3 800/ 1066
2 гнезда платы памяти DDR3 DIMM, максимальная память до 16 Гб
Каждый модуль DIMM поддерживает модуль не-ECC 512 Мб/ 1/ 2/ 4/ 8 Гб DDR3
* Перечень поддержки памяти смотрите на
www.biostar.com.tw.
Накопитель Соединитель 3x SATA 6 Гб/с, Поддерживает родной IDE & AHCI режим
Локальная сеть
Realtek RTL 8111F
Автосогласование 10/ 100/ 1000 Мб/с, работает в полно/полудуплексном режиме
Аудиокодек
ALC662
Каналы 5.1, высококачественное аудио
USB
2 порта USB 3.0 (2 сзади ввода-вывода)
6 порта USB 2.0 (2 сзади ввода-вывода и 4 через внутренние контакты)
Гнезда расшир. 1x PCIe 2.0 x16 гнездо (x4)
Задняя плата
ввода-вывода
1 мышь PS/2
1 клавиатура PS/2
1 порт HDMI
1 порт VGA
1 порт локальной сети
2 порта USB 2.0
2 порта USB 3.0
3 гнезд для подключения наушников
Внутр. Плата
ввода-вывода
Соединитель 3x SATA 6 Гб/с
2 контакта USB 2.0 (каждый контакт поддерживает 2 порта USB 2.0)
1 4-выводный разъем питания
1 24-выводный разъем питания
1 разъем вентилятора ЦП
1 разъема вентилятора системы
1 контакт передней панели
1 контакт передней аудиопанели
1 контакт микросхемы Clear CMOS
1 контакт порта принтера
1 контакт последовательного порта
1 соединитель S/PDIF-Out
