Motherboard Manual
30
German
Spezifikationen
CPU-Unterstützung AMD E-350D (A68I-350 DELUXE/ A68I-350 DELUXE R2.0) / AMD C-60 (A68I-C60)
Chipset AMD A68 FCH
Festplattenspeicher
Unterstützt single-channel DDR3 800/ 1066
2 x DDR3 DIMM-SpeicherSlot, Max. Uterstützung bis zu 16 GB-Speicher
Jedes DIMM unterstützt nicht-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3-Module
* Bitte konsultieren Sie
www.biostar.com.tw für für Speicherunterstützung Liste.
Arbeitsspeicher 3x SATA 6Gb-Verbindung, Unterstützt Ureinwohner IDE & AHCI Modus
LAN
Realtek RTL 8111F
10/ 100/ 1000 Mb Auto-Negotiation, Halb- / Voll-Duplex-fähig
Audio-Codec ALC662, 5.1 Kanäle, HD-Audio
USB
2x USB 3.0-Port (2 hintere I/Os)
6x USB 2.0-Port (2 hintere I/Os und 4 via interne Header)
Erweiterungsanschl
üsse
1x PCIe 2.0 x16-Slot (x4)
Hintere I/Os
1x PS/2-Maus
1x PS/2-Keyboard
1x HDMI-Port
1x VGA-Port
1x LAN-Port
2x USB 2.0-Port
2x USB 3.0-Port
3x Audio Jack
Interne I/Os
3x SATA 6.0Gb/s-Verbinung
2x USB 2.0-Header (jeder Header unterstützt 2 USB 2.0-Ports)
1x 4-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
1x CPU-Ventilatorverbindung
1x System-Ventilatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
1x Header für Druckerport
1x Serieller Port-Header
1x S/PDI-Auswurfsverbindung
Formfaktor mini-ITX Formfaktor, 170 mm x 170 mm
