Motherboard Manual
32
Italian
Specificazioni
Supporto
processore
AMD E-350D (A68I-350 DELUXE/ A68I-350 DELUXE R2.0) / AMD C-60 (A68I-C60)
Tipo scheda AMD A68 FCH
Memoria
Supporta DDR3 800/ 1066 Singolo Canale
2 x DDR3 DIMM Slot di Memoria Supporta fino a 16 GB Memoria
Ogni DIMM supporta non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 moduli
* Si prega di consultare
www.biostar.com.tw per la lista di supporto del memoria.
Memorizzazione
Connettore 3x SATA 6Gb/s
Supporta nativo IDE & AHCI modo
Catena
Realtek RTL 8111F
10/ 100/ 1000 Mb auto negoziazione, capacita di duplex Meta / Completo
Codec Audio
ALC662
Canali Audio di Alta Definizione 5.1
USB
Slot 2x USB 3.0 (2 nei ingressi/ uscite posteriore)
Slot 6x USB 2.0 (2 nei ingressi/ uscite posteriore e 4 da distributori interni)
Slot di espansione Slot 1x PCIe 2.0 x16 (x4)
Ingressi/ Uscite
Posteriore
Mouse 1x PS/2
Tastiera 1x PS/2
Slot 1x HDMI
Slot 1x VGA
Slot 1x LAN
Slot 2x USB 2.0
Slot 2x USB 3.0
Jack audio 3x
Ingressi/ Uscite
Interni
Connettore 3x SATA 6.0Gb/s
Distributore 2x USB 2.0(ogni distributore supporta 2 slot USB 2.0)
Connettore con 4 pin x1
Connettore con 24 pin x1
Connettore Ventilatore processore x1
Connettore Ventilatore Sistema x1
Distributore Pannello Frontale x1
Distributore Audio Frontale x1
Distributore CMOS Diretto x1
Distributore Slot Stampante x1
Distributore Slot Serie x1
Connettore esterno S/PDIF x1
