Motherboard Manual
36
Polish
Specyfikacje techniczne
Obsługa procesora AMD E-350D (A68I-350 DELUXE/ A68I-350 DELUXE R2.0) / AMD C-60 (A68I-C60)
Rodzaj płyty AMD A68 FCH
Pamięć
Pojedynczy pamięci DDR3 800/ 1066 Dwukanałowa
2 x DDR3 DIMM Pamięć Gniazda procesora (Slot), Maksymalna wielkość pamięci 16 GB
Każdy DIMM obsługuje jeden moduł non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3
* Proszę sprawdzić listę obsługiwanych pamięć na stronie internetowej
www.biostar.com.tw
Przechowywanie Złącze 3x SATA 6Gb/s, Obsługa rodzimy IDE & AHCI tryb
LAN
Układ RTL 8111F
10/ 100/ 1000 Mb auto negocjacja, pojemność dupleks Połowe / Pełny
Codec Audio
ALC662
Kanały Audio wysokiej Definicji 5.1
USB
2 x złącza USB 3.0 (2 przez tylne porty wejścia/ wyjścia oraz)
6 x złącza USB 2.0 (2 przez tylne porty wejścia/ wyjścia oraz 4 przez wewnętrzne porty)
Złącza rozszerzeń złącza 1x PCIe 2.0 x16 (x4 Slot)
Tylne porty wejścia/
wyjścia
Myszka 1x PS/2
Klawiatura 1x PS/2
Port 1x HDMI (gniazdo)
Port 1x VGA
Port 1x LAN
Porty 2x USB 2.0
Porty 2x USB 3.0
Porty audio 3x
Wewnętrzne porty
wejścia/ wyjścia
Złącza 3x SATA 6.0Gb/s
Złącza 2x USB 2.0 (każde złącze obsługuje dodatkowe 2 porty USB 2.0)
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora CPU x 1
Złącze wentylatora obudowy x 1
Złącze przedniego panelu x1
Złącze audio przedniego panelu x1
Złącze bezpośrednie CMOS x1
Złącze port drukarki x1
Port szeregowy x1
Port zewnętrzny S/PDIF x1
Obudowa Obudowa mini-ITX, 170 mm x 170 mm
