APPENDIX I: Specicaons in Other Languages | 29
A68N-5745 / A68N-5545 / A68N-5600
Spanish
Especicaciones
Compabilidad con el
procesador
A68N-5545: A8-5545M (Quad core 1.7GHz up to 2.7GHz, 19W)
A68N-5600: A10-4655M (Quad core 2.0GHz up to 2.8GHz, 25W)
A68N-5745: A10-5745M (Quad core 2.1GHz up to 2.9GHz, 25W)
Tipo de Placa
AMD A70M FCH (A68N-5745 / A68N-5545)
AMD A68H (A68N-5600)
Memoria
Soporta DDR3 1333 Doble Canal
2x DDR3 DIMM Ranura de memoria Soporta hasta 32 GB Memoria
Cada DIMM soporta un modulo non-ECC 4/ 8/ 16 GB DDR3
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 4x SATA III (6Gb/s) : Soporta AHCI & RAID 0,1,10
LAN
Realtek RTL 8111H
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC887
Canales Audio de Alta Denición 7.1
USB
A68N-5745 / A68N-5545:
Ranura 4x USB 3.0 (2 en las entradas/salidas posteriores y 2 por los distribuidores internos)
Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores internos)
A68N-5600:
Ranura 2x USB 3.0 (2 en las entradas/salidas posteriores)
Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores internos)
Ranuras de Exnción Ranura 1x PCIe 2.0 x16 (x8)
Panel trasero de E/S
Ratón 1x PS/2
Teclado 1x PS/2
Ranura 1x VGA
Ranura 1x HDMI
Ranura 1x LAN
Ranura 2x USB 3.0
Ranura 2x USB 2.0
Socket audio 3x
Conectores en placa
A68N-5745 / A68N-5545:
Conector 4x SATA III 6Gb’s
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2
ranuras USB 2.0)
Distribuidor 1x USB 3.0 (cada distribuidor soporta 2
ranuras USB 3.0)
Conector con 4 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x1
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Ranura Serie x1
A68N-5600:
Conector 4x SATA III 6Gb’s
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2
ranuras USB 2.0)
Conector con 4 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x1
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Ranura Serie x1
Factor de Forma Factor de Forma Mini-ITX, 170 mm x 170 mm
Soporte OS
Windows 7/ 8/ 8.1/10
Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
