第四章:帮助信息 | 25
A68N-5745 / A68N-5545 / A68N-5600
4�5 AMD双显卡技术
AMD双显卡技术介绍
当用户添加一块PCIE显卡时,便可以和内置的显卡整合在一起,达到更好的效果。为了使
两个显卡设备同时正常运行,请参照下面的设置。
AMD双显卡要求
• 双显卡只能支持与双通道内存配置
• 操作系统: Windows 7 / Windows 8 / Windows 8.1
• 支持的双显卡组合:
Kaveri APUs
AMD Radeon™ Graphics Card
A10-Series
Radeon™ R7
A8-Series
Radeon™ R7
A6-Series
Radeon™ R5
“Oland” XT, R7 250 ●(Note2) ●(Note2)
Under Investigation
“Oland” Pro 6CU, R7 240 ●(Note2) ●(Note2)
“Oland” Pro 5CU, R7 240 ●(Note2) ●(Note2)
“Oland” Pro 64b, R7 240 -- --
Richland APUs
AMD Radeon™ Graphics Card
A10-Series
HD 8670D
A8-Series
HD8570D
A6-Series
HD 8470D
“Oland” XT, HD 8870 ● ● ●(Note2)
“Oland” Pro, HD 8850 ● ● ●
“Turks” XT, HD 6670 ● ● ●
“Turks” Pro, HD 6570 ● ● ●
“Caicos” Pro, HD 6450 ● ● ●
Trinity APUs
AMD Radeon™ Graphics Card
A10-Series
HD 7660D
A8-Series
HD7560D
A6-Series
HD 7540D
“Turks” XT, HD 6670 ● ● --
“Turks” Pro, HD 6570 ● ● ●
“Caicos” Pro, HD 6450 -- -- ●
»
●
此标志为AMD双显卡所推荐的显卡
»
A 4系 列 产 品 不支 持 双 显卡。
»
仅供DDR3显卡内存。
»
本手册上面描述的信息仅供参考，实际主板信息和设置可能与手册略有差异。若要获知详细的
AMD双显卡信息，请访问网站：http://www.amd.com
