Ariston CP98SEA [22/76] Start up and use

Start-up and use

Using the hob

Lighting the burners

For each BURNER knob there is a complete ring

showing the strength of the flame for the relevant

burner.

To light one of the burners on the hob:

1. Bring a flame or gas lighter close to the burner.

2. Press the BURNER knob and turn it in an

anticlockwise direction so that it is pointing to the

maximum flame setting E.

3. Adjust the intensity of the flame to the desired

level by turning the BURNER knob in an

anticlockwise direction. This may be the minimum

setting C, the maximum setting E or any position in

between the two.

If the appliance is fitted with

an electronic lighting device*

(

see figure

), press the

BURNER knob and turn it in

an anticlockwise direction,

towards the minimum flame

setting, until the burner is lit.

The burner might be

extinguished when the knob is released. If this

occurs, repeat the process, holding the knob down

for a longer period of time.

! If the flame is accidentally extinguished, switch off

the burner and wait for at least 1 minute before

attempting to relight it.

If the appliance is equipped with a flame failure

safety device*, press and hold the BURNER knob

for approximately 2-3 seconds to keep the flame

alight and to activate the device.

To switch the burner off, turn the knob until it

reaches the stop position •.

The "independent double flame" burner*

This gas burner consists of two concentric flame

rings which can be used together or independently

of each other. Using both simultaneously at

maximum power makes it possible to reach a higher

overall power level, thus reducing cooking time with

respect to the time required by traditional burners.

The double flame ring also distributes heat more

evenly across the base of the pan, especially when

both burners are set to the minimum power level.

To ensure that the double-flame burner is used to

its full potential, never set the inside ring to

minimum and the outside ring to maximum at the

same time.

Cookware of all sizes may be used; when cooking

with small recipients use only the inner burner. Each

individual ring with an "independent double flame

burner" has its own control knob:

the knob marked with the symbol

controls the

outer ring;

the knob marked with the symbol

controls the

inner ring.

To light the desired ring, press the corresponding

knob fully in and turn it in an anticlockwise direction

until it reaches the maximum power position E

The

burner is equipped with an electronic lighting

system which is activated automatically when the

knob is pressed.

As the burner is fitted with a safety device, the

knob should be held down for approximately 2-3

seconds, until the automatic device keeping the

flame alight has heated up.

Each burner can be adjusted to one of the following

settings using the corresponding control knob:

• Off

• Maximum

• Minimum

To switch off the burner, turn the knob in a clockwise

direction until it stops (when it reaches the "•"

position).

Practical advice on using the burners

For the burners to work in the most efficient way

possible and to save on the amount of gas

consumed, it is recommended that only pans which

have a lid and a flat base are used. They should

also be suited to the size of the burner.

Burner

Rapid (R)

Semi-rapid (S)

Auxiliary (A)

Triple.ring (TC)

Double flame (DCDR internal)

Double flame (DCDR external)

Ø Cookware Diameter (cm)

24 - 26

16 - 22

10 - 14

24 - 26

10 - 14

26 - 28

To identify the type of burner, please refer to the

diagrams contained in the paragraph entitled

“Burner and nozzle specifications”.

! Make sure the pans do not overlap the edges of

the hob while it is being used.

Only available in certain models.
