Planet WAP-7000 [14/29] Ip address

Type Password Again

Re-type the new password again.

SSH Server

Enable or disable the built-in SSH server. SSH is a secured telnet-like mechanism to invoke

the command line interface. All the commands and response will be encrypted. The SSH port

is 22. You need to have an SSH client to access SSH server.

SNMP Community

Enter the community string, usually either "Public" or "Private".

Trap Receiver

Trap is the notification of certain events generated by SNMP agent to send to a network

management server. To have the WAP-7000 send SNMP trap, you need to enter the IP

address of the server where the trap is sent.

There are two trap messages, "Cold Start" and "Link Up", are supported. They are sent out

whenever the system is started.

UPDATE

Click “Update” and then “Reboot” button when you finish setting up for parameter changes

taking effect.

4.2 IP Address

There are two methods to assign IP address to WAP-7000: Manually configure or DHCP.

- 10 -
