Discarded Frame
Displays the number of transmit discarded frames.
Excessive Retry Frame
Displays the number of transmit excessive retries.
4.5 File Upload
This screen allows you to upgrade your WAP-7000 when new firmware is released.
To perform the Firmware Upgrade:
1. Click the “Browse” button and navigate to the location of the upgrade file.
2. Select the upgrade file. Its name will appear in the Upgrade File field.
3. Click the “Upload & Update” button to commence the firmware upgrade.
Note 1: The WAP-7000 is unavailable during the upgrade process, and must restart when the upgrade is
completed. Any connections to or through the WAP-7000 will be lost.
Note 2: In case network disruption happens during file uploading, system will keep on running with
current active firmware. You may perform the file upload again when network is back to normal.
- 19 -
