Unique Key (Master Bridge only)

In some special applications, you may need to assign different key for each Master-Slave link

instead of the same key for all links. It can be done by setting up a Unique Key for each Slave

Bridge. The MAC addresses of the Slave Bridge will be shown in the Bridge MAC field. Please

input the key value for corresponding Slave Bridge in the Key field. The key value must be

complied with the encryption type as well.

Encryption Key (Slave Bridge only)

For Slave Bridges of a Point-to-Multipoint bridging network, the Encryption Key need to be the

same with Unique Key setting assigned to this Slave Bridge. Or, if there is no corresponding

Unique Key being assigned on Master Bridge, then Slave Bridge should follow the Share Key

assigned on Master Bridge.

UPDATE

Click “Update” and then “Reboot” button when you finish setting up for parameter changes

taking effect.

4.4 Bridge Statistics

This screen shows you the information about the Local and Remote Bridges that are in the same BSS

(Basic Service Set).

Clicking MAC address hyperlink of desired device, system will show a Statistics page for you to monitor

the bridge link.
