1.3 Specification
Model WAP-7000
Standard support IEEE802.11a
IEEE802.3
IEEE802.3u
Interface Wireless IEEE802.11a
One 10/100 RJ-45 port
Data Rate 6, 9, 12, 18, 24, 36, 48, 54Mbps
Modulation OFDM
RF Output Power 18dBm (typical)
Receiver Sensitivity 6 Mbps: -82dBm
9 Mbps: -81dBm
12 Mbps: -79dBm
18 Mbps: -77dBm
24 Mbps: -74dBm
36 Mbps: -70dBm
48 Mbps: -66dBm
54 Mbps: -65dBm
Media Access Technology CSMA/CA
Lightning Protection Built-in
Antenna Connector N-Type
Dimensions 320m x 310mm x 48mm (W x D x H)
Weight 3.05kg
Environmental Specification
Operating temperature: -20 – 70 degree C
Storage temperature: -40 – 80 degree C
Relative humidity: 10% – 90% (non-condensing)
Power Requirement 48V DC, 1.37A (proprietary PoE)
Electromagnetic
Compatibility
FCC, CE
1.4 Wireless Performance
The following information will help you utilizing the wireless performance, and operating coverage of
WAP-7000.
1. Site selection
To avoid interferences, please locate WAP-7000 away from transformers, microwave ovens,
heavy-duty motors, refrigerators, fluorescent lights, and other industrial equipments.
- 2 -
