Super Bridge Mode

Super Bridge Mode provides three mechanisms to improve the bridge throughput.

Compression: Frame is compressed by hardware before transmitting. Note that the

compression may save bandwidth but would consume frame process time. In case of the data

is already compressed (eg. mpeg frame), please do NOT turn on this function.

Bursting: Turning on Bursting function enables multiple frames are transmitted at SIFS

intervals, which may reduce transmission overhead.

Fast Frame: Turning on Fast Frame function enables two Ethernet frames bundled into a

single wireless frame.

Note: It is required to setup the same options of Super Bridge Mode between Bridges to

communicate.

Auto Reboot

When this function is enabled, Bridge will reboot itself automatically while there is no data

received for 30 seconds. This function is disabled by default.

Spanning Tree Protocol

This function is to prevent the network loop and disabled by default. It is suggested you enable

this function when the network configuration is complicated.

UPDATE

Click “Update” and then “Reboot” button when you finish setting up for parameter changes

taking effect.

4.3.1 Bridge Security

This page is shown after clicking the “Setup” button in the “Bridge Security” field of “5GHz Bridge” page. It

looks a little different when the device is configured in Master Bridge and Slave Bridge mode.
