Values on this page are automatically refreshed every one-minute. You may manually click the refresh
button of browser to get the most updated data more frequent. As RF signal strength is more critical for
outdoor deployment purpose, RSSI bar is refreshed every 2 seconds. Due to frequent refresh of Statistics
page, it is strongly recommended that you close this page when performing network performance tests.
Encryption
Displays current state of encryption; the value is Yes or No.
MSDU
Displays the number of MAC Service Data Unit received and transmitted by the monitored
bridge.
Data / Management / Control Frame
Packets can be data, management or control. Displays the number of packets sent and
received for each.
Multicast Frame
Displays the number of multicast frames.
- 17 -
