Image Flip According to camera position, user might need this function to
correct the view angle avoiding upside down. User can chose to
enable or disable this function by toggling the icon below.
: Disable audio uploading function.
: Enable audio uploading function.
Image Mirror According to camera position, user might need this function to
correct the view angle. User can chose to enable or disable this
function by toggling the icon below.
: Disable vertical flip function.
: Enable vertical flip function.
ActiveX Control The plug-in ActiveX control supports a lot of functions by clicking the
left mouse button. Note that this feature only supports on the ActiveX
control within Microsfoft® Internet Explorer.
This function is detail setting for the camera that only available for
user logged into camera as administrator.
Item Action
Network
Configure Network settings such as Wireless,
DHCP, DDNS, 3GPP, PPPoE and UPnP.
Camera Adjust camera parameters.
System
Configure system information, date & time,
maintenance, and view system log file.
Video
Configure bit rate and frame rate of video
profiles.
Audio Configure audio parameters.
User Setup user name, password and login privilege.
E-Mail Setup E-Mail configuration.
FTP
This devise is a client site and configure
information to upload images to server.
Object Detection Setup Object detection.
Setting Menu
Event Schedule Configure the schedule while event triggered.
Streaming Protocol User can select proper streaming protocol according to networking
environment.
30
