Appendix I: Product Specification
Product ICA-H651
Video Specification
Horizontal Resolution 480 TV Lines
Sensor 1/4” Color SONY super HAD CCD
Frequency: 15,734 Hz (H), 60 Hz (V), Pixel: 811(H) x 508(V)
Sensor Elements
Frequency: 15,625 Hz (H), 60Hz (V), Pixel: 795(H) x 596(V)
Lens Type
23X optical zoom, 10X digital zoom
View Angle
H: 2 ~ 68 Degree / V: 1 ~ 54 Degree
Lens
F1.6~3.8/ f 3.8 ~ 87.4 mm
Image Control AGE, AES, BLC
Focus
Auto / Manual
Image (Video Setting
)
Video Encoder H.264 / MPEG-4 / M-JPEG simultaneously
Video Resolution D1 (704 x 576), CIF(358 x 288), QCIF(176 x 144), 30fps for all resolution
Network and Configuration
Network Interface Ethernet 10Base-T/100Base-TX
Networking Protocol TCP, UDP, HTTP, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP, Bonjour, UPnP,
RTSP, RTP, RTCP, PPPoE, 3GPP, ICMP
Browser / Software
Microsoft ® Internet Explorer 6.0 or later, Cam Viewer Plus Lite/Pro
Hardware
Pan Degree 0 ~ 360 degree continuous panning
Tilt Degree 90 degree with instant flip
Preset Point 64 present points
Camera Tour 16 tours
Audio in / Audio out 1 x MIC in / 1 x Line out
Video Output 1.0 Vp-p / 75ohm (BNC connector)
2-Way Audio Simplex / Duplex 2-Way audio
DI / DO ports DI:1 / DO:1(dry contact)
RS-485 RS-485 for external keyboard
Protection Class IP-66 outdoor classification, Built-in Fan and Heater
Dimension (mm) 220(W) x 390(D) x 336(H)
Weight 8kg
Power Supply 24V AC , 2A external power adapter
Operating Temperature -20 – 50 Degree C
Operating Humidity 20 – 80% (non-
condensing
)
Emission CE, FCC
