3.3 Live View
Start-up screen will be as follow no matter an ordinary users or an administrator.
A
ctiveX Control
Streaming Protocol
Video Profile
Language
Setting Menu
Monitor Image Section
Video Information
Ima
g
e Mirro
r
Full Screen
Image Flip
2-Wa
y
Audio
Client Menu
PTZ Control
OSD Control
Monitor Image
Section
The image shot by the camera is shown here. The date and time are
displayed at the top of the window.
Video Profile The camera support multi-profile for three compressions H264,
MEPG-4 and M-JPEG simultaneously. User can chose the proper
and/or preferred profile here.
Full Screen Click this button to display the image in full-screen mode (uses every
available space to display the image captured by this camera).
2-Way Audio The Internet camera supports 2-way audio function. User can chose
to enable or disable this function by toggling the icon below
: Disable audio uploading function.
: Enable audio uploading function.
29
