3.6.2 PTZ Setting

Camera Protocol This device can connect to a PTZ camera or speed dome camera

and controls them thru RS-485 interface.

Note: please DO NOT change the default value if unnecessary. If so, user needs to check

and set value properly for both sides.

Camera Address This is the camera ID set in PTZ camera or speed dome camera.

Baud rate This is the communication speed between network module and P/T

scanner.

Note If need to change these parameters, user needs to check and set value properly for

both, network module and P/T scanner.

OSD Control Choose the corresponding model for OSD control

OSD Open Control commands for Open function.

OSD Close Control commands for Close function.

OSD Select Control commands for Select function.

OSD Back Control commands for Back function.

OSD Up Control commands for Up function.
