42
RTSP Port Choose the RTSP port. The RTSP protocol allows a connecting client to
start a video stream. Enter the RTSP port number to use. The default value
is 554.
RTP Port Specify the range of transmission port number of video stream. The default
range is 50000 to 50999. User can specify a number between 1024 and
65535.
NOTE 1. To use the 3GPP function, in addition to previous section, you might
need more information or configuration to make this function work.
2. The camera must be set as Multi-profile mode, not Mega-pixel mode.
Otherwise this device cannot serve 3GPP stream.
3. To use the 3GPP function, it strongly recommends installing the
Networked Device with a public and fixed IP address without any
firewall protection.
4.
Port 554 is the default for RTSP service. However, sometimes, some
service providers change this port number for some reasons. If so,
user needs to change this port accordingly.
Dialing
procedure
1. Choose a verified player (PacketVideo, Quicktime or Realplayer
currently)
2. Use the following URL to access: rtsp://host/mpeg4/media.3gp
Where host is the host name or IP address of the camera.
Compatible
3G mobile
phone
Please contact your dealer to get the approved list of compatible 3G
phone.
