89
z
Make sure that the device isn’t conflicting with any other web
server running on your LAN.
z
Check the configuration of the router settings allow the device to
be accessed outside your local LAN.
z
Check the bandwidth of Internet connection. If the Internet
bandwidth is lower than target bit rate, the video streaming will
not work correctly.
The unreadable characters are
displayed.
Use the operating system of the selected language. Set the
Encoding or the Character Set of the selected language on the
Internet Explorer.
Frame rate is slower than the
setting.
z
The traffic of the network and the object of the image affect the
frame rate. The network congestion causes frame rate slower
than the setting.
z
Check the bandwidth of Internet connection. If the Internet
bandwidth is lower than target bit rate, the video streaming will
not work correctly.
z
Ethernet switching hub can smooth the frame rate.
Blank screen or very slow video
when audio is enabled.
z
Your connection to the device does not have enough bandwidth
to support a higher frame rate for the streamed image size. Try
reducing the video streaming size to 160x120 or 320x240 and/or
disabling audio.
z
Audio will consume 32 kbps. Disable audio to improve video.
Your Internet connection may not have enough bandwidth to
support streaming audio from the device.
Image Transfer on e-mail or FTP
does not work.
z
Default Gateway and DNS server address should be set up
correctly.
z
If FTP does not work properly, ask your ISP or network
administrator about the transferring mode of FTP server.
Pan/Tilt does not work. (including
Click to Center and Preset
Positioning)
z
Click “Refresh” on the Internet Explorer when the communication
stops with the device. The image will refresh.
z
Other clients may be operating Pan/Tilt.
z
Pan/Tilt operation has reached the end of corner.
Pan/Tilt does not work smoothly. There may be a slight delay when you are using the Pan/Tilt feature
in conjunction with streaming audio and video. If you find that there
is a significant delay while panning or tilting the camera, try disabling
the audio streaming and/or reducing the video streaming size.
Video quality of the device
The focus on the Camera is bad. The lens is dirty or dust is attached. Fingerprints, dust, stain, etc. on
the lens can degrade the image quality.
