Ariston BWMD 742 [9/56] Wash cycles and functions
![Ariston BWMD 742 [9/56] Wash cycles and functions](/views2/1071474/page9/bg9.png)
GB
9
Wash cycles and functions
Wash functions
Super Wash
This option offers a high-
performance wash due to the
greater quantity of water used
in the initial phase of the cycle,
and due to the increased wash
cycle duration, is particular-
ly useful for the removal of
stubborn stains. It can be used
with or without bleach. If you
desire bleaching, insert the
extra tray compartment (4) into
compartment 1. When pouring
in the bleach, be careful not to
exceed the “max” level marked
on the central pivot (see figure). To bleach laundry without
carrying out a full wash cycle, pour the bleach into the extra
compartment 4, select the “Rinse” cycle and activate the
“Super Wash” option.
! The use of extra compartment 4 excludes the “Pre-wash”
function.
! It cannot be used with the , , , , “Spin”, “Pump out”.
Extra Rinse
By selecting this option, the efficiency of the rinse is increased
and optimal detergent removal is guaranteed. It is particularly
useful for sensitive skin.
! It cannot be used with the “Fastwash 30’”, , , “Spin”,
“Pump out”.
Table of wash cycles
Easy Iron
By selecting this function, the wash and spin cycles will be modified
in order to reduce the formation of creases. At the end of the cycle
the washing machine will perform slow rotations of the drum; the
EASY IRON and START/PAUSE indicator lights will flash (orange)
and the text “END OF CYCLE” will appear on the display. To end
the cycle, press the START/PAUSE button or the EASY IRON
button. To drain the water so that the laundry may be removed,
press the START/PAUSE button or the EASY IRON button.
! It cannot be used with the , “Fastwash 30’”, , , .
Prewash
If this function is selected, the pre-wash cycle will run; this is
useful for removing stubborn stains.
N.B.: put the detergent in the relevant compartment.
! It cannot be used with the , , , , ,
(60°), (40°),
.
Eco Wash
The Eco Wash function saves energy by not heating the
water used to wash your laundry – an advantage both to the
environment and to your energy bill. Instead, intensified wash
action and water optimisation ensure great wash results in the
same average time of a standard cycle.
For the best washing results we recommend the usage of a
liquid detergent.
! It cannot be used with the , , , , , .
M
AX
1
2
4
3
Wash cycles
Description of the wash cycle
Max. temp.
(°C)
Max. speed
(rpm)
Detergents
Max. load
(kg)
Residual dam-
pness %
Energy con-
sumption kWh
Total water lt
Cycle duration
Prewash
Wash
Fabric
softener
Bleach
Anti Stain
40° 1400
4 - -
-
180’
Standard Cotton 60° (1) (1st press of the button): heavily soiled whites and
delicate colours.
60°
(Max. 90°)
1400
(3)
7 53 1,1 58 190’
Standard Cotton 40° (2) (2nd press of the button): lightly soiled whites and
delicate colours.
40° 1400 -
7 53 0,99
82
185’
Standard Cotton 20° (3rd press of the button): lightly soiled whites and
delicate colours.
20° 1400 -
7 - -
-
170’
Synthetics Resistant (1st press of the button): heavily soiled resistant colours. 60° 800
3 44 0,93 47 110’
Synthetics Resistant (4) (1st press of the button): lightly soiled resistant colours. 40° 800
3 44 0,57 46 95’
Synthetics Delicate (2nd press of the button): lightly soiled resistant colours. 40° 800
3 - - - 70’
Fastwash 60' (1st press of the button): to refresh normal soiled garments quic-
kly (not suitable for wool, silk and clothes which require washing by hand).
60° 1400 -
- 3,5 53 0,81 40 60’
Fastwash 30' (2nd press of the button): to refresh lightly soiled garments quic-
kly (not suitable for wool, silk and clothes which require washing by hand).
30° 800 -
- 3 71 0,15 35 30’
M
My Cycle: allows for any wash cycle to be stored.
Anti Allergy
60° 1400 -
- 4 - - - 195’
Woolmark Platinum (Wool): for wool, cashmere, etc. 40° 800 -
- 1,5 - - - 70’
Delicates
30° 0 -
- 1 - - - 80’
Spin (1st press of the button) - 1400 - - - - 7 - - - 16’
Rinse (2nd press of the button) - 1400 - -
7 - - - 36’
Pump out (3rd press of the button) - 0 - - - - 7 - - - 2’
The length of cycle shown on the display or in this booklet is an estimation only and is calculated assuming standard working conditions. The actual duration can vary according to factors
such as water temperature and pressure, the amount of detergent used, the amount and type of load inserted, load balancing and any wash options selected.
1) Test wash cycle in compliance with directive 1061/2010: set wash cycle 60°C (1st press of the button).
This cycle is designed for cotton loads with a normal soil level and is the most efficient in terms of both electricity and water consumption; it should be used for garments which can be
washed at 60°C. The actual washing temperature may differ from the indicated value.
2) Test wash cycle in compliance with directive 1061/2010: set wash cycle 40°C (2nd press of the button).
This cycle is designed for cotton loads with a normal soil level and is the most efficient in terms of both electricity and water consumption; it should be used for garments which can be
washed at 40°C. The actual washing temperature may differ from the indicated value.
3) At 60 °C the “Prewash” function cannot be selected.
For all Test Institutes:
2) Long wash cycle for cottons: set wash cycle 40°C (2nd press of the button).
4) Long wash cycle for synthetics: set wash cycle 60°C (1st press of the button); temperature of 40°C (press TEMPERATURE button).
