Planet VIP-281 [11/57] Wan ip address configuration via web configuration interface

Note

Please locate your PC in the same network segment

(172.16.0.x) of VIP-281GS. If you’re not familiar with

TCP/IP, please refer to related chapter on user’s manual

CD or consult your network administrator for proper network

configurations.

WAN IP address configuration via web configuration interface

Execute your web browser, and insert the IP address (default: 172.16.0.1) of VIP in the adddress bar.

After logging on machine with username/password (default: admin / 123), browse to “WAN Setting”

configuration menu, you will see the configuration screen below:

Figure 2-2. WAN port configuration

Connection Type Data required.

Static IP

The ISP will assign IP Address, and related information.

DHCP

Get WAN IP Address automatically; it is no need to

configure the DHCP settings.

PPPoE

The ISP will assign PPPoE username / password for

Internet access,

Table 2-1. WAN port configuration descriptions

Please consult your ISP personnel to obtain proper PPPoE/IP

address related information, and input carefully.

If Internet connection cannot be established, please check

the physical connection or contact the ISP service staff

for support information.

Hint
