NAT Pass Setting

NAT Pass Method

Default use Symmetric RTP pass function.

STUN Client

Setting your STUN server information, default STUN server is

FWD STUN server.

Outbound Proxy

Support

Setting your Outbound Proxy server information.

Local SIP Port

Setting local use SIP port, default is 5060.

Table 5-13. SIP proxy descriptions

Dialing Plan to SIP protocol

The “Dialing plan” needs setting when the user uses the method of Peer-to-Peer or registering SIP

proxy server mode. The SIP dialing plan has two kinds of directions: Outgoing (call out) and incoming

(call in).

Outgoing Dial Plan

Peer-to-Peer call mode: Effective

Registering to SIP Proxy Server Mode: Effective

Incoming Dial Plan

Peer-to-Peer call mode: Effective

Registering to SIP proxy server mode: The leading number would

Table 5-14. Dialing plan descriptions

Figure 5-20. Outgoing dial plan setting

In the “Outgoing Dial Plan Configurations” settings: Maximum Entries : 50

Outbound number

The leading digits of the call out dialing number.

Length of Number

It has two text fields need filled: “Min Length” and “Max Length” is

the min/max allowed length you can dial.

Delete Length

The number of digits that will be stripped from beginning of the

dialed number.

Prefix no.

The digits that will be added to the beginning of the dialed number.
