IDL series User Guide
584
Command Syntax:
create snmp host ip <ip-address > community <community-val >
5.23.2.3 Delete snmp host
Description:
Use this command to delete.
Command Syntax:
delete snmp host ip <ip-address > community <community-val >
Parameter:
Name Description
ip <ip-address >
This specifies the IP address of the manager that
has access permissions.
Type: Create － Mandatory
Delete － Mandatory
Get － Optional
community
<community-val >
This specifies the Community name. This must
be a valid community in the snmp community
table.
Type: Create － Mandatory
Delete － Mandatory
Get － Optional
Example:
$ create snmp host ip 172.25.34.34 community public
Output:
Verbose Mode On
Entry Created
Host Address Community
--------------------------------------------------------------
172.25.34.34 public
Verbose Mode Off:
Entry Created
