IP DSLAM
585
Output field:
Field Description
Ip Address
This specifies the IP address of the manager that
has access permissions.
Community
This specifies the Community name. This must
be a valid community in the snmp community
table.
References:
z SNMP commands
5.23.3 SNMP Stats Commands
5.23.3.1 Snmp stats
Description:
Use this command to get.
Command Syntax:
get snmp stats
5.23.3.2 Modify snmp stats
Description:
Use this command to modify.
Command Syntax:
modify snmp stats [authentraps enable | disable]
Parameter:
Name Description
authentraps enable
|disable
Indicates whether the SNMP agent process is
permitted to generate authentication-failure
traps. The value of this object overrides any
configuration information; as such, it provides a
means whereby all authentication-failure traps
may be disabled.
Type: Modify － Optional
Default value: disable
