Planet XRT-401D [19/62] Cable modem

2.1 Cable Modem

Choose Cable Modem if your ISP will automatically give you an IP address. Some ISP’s may also

require that you fill in additional information such as Host Name and MAC address (see screen

below).

Note:

The Host Name and MAC address section is optional

and you can skip this section

if your ISP does not require these settings for you to connect to the Internet.

Parameters Description

Host Name If your ISP requires a Host Name, type in the host name

provided by your ISP, otherwise leave it blank if your ISP does

not require a Host Name.

MAC Address Your ISP may require a particular MAC address in order for you

to connect to the Internet. This MAC address is the PC’s MAC

address that your ISP had originally connected your Internet

connection to. Type in this MAC address in this section or use

the “Clone MAC Address” button to replace the WAN MAC

address with the MAC address of that PC (you have to be using

that PC for the Clone MAC Address button to work). To find out

the PC’s MAC address see Appendix A. (see Glossary for an

explanation on MAC address)

Click <OK> when you have finished the configuration above. Congratulations! You have

completed the configuration for the Cable Modem connection. You can start using the router now,

if you wish to use some of the advance features supported by this router see chapter 3, 4, 5.
