20
Chapter 3 General Settings
Once you click on the General Setup button at the Home Page, you should see the screen below.
If you have already configured the Quick Setup Wizard you do NOT need to configure anything
thing in the General Setup screen for you to start using the Internet.
The General Setup contain advanced features that allow you to configure the router to meet your
network’s needs such as: Address Mapping, Virtual Server, Access Control, Hacker Attack
Prevention, Special Applications, DMZ and other functions.
Below is a general description of what advance functions are available for this broadband router.
Menu Description
3.1 System This section allows you to set XRT-401D’s system Time Zone,
Password and Remote Management Administrator.
3.2 WAN This section allows you to select the connection method in order
to establish a connection with your ISP (same as the Quick
Setup Wizard section)
3.3 LAN You can specify the LAN segment’s IP address, subnet Mask,
enable/disable DHCP and select an IP range for your LAN
3.4 NAT You can configure the Address Mapping, Virtual Server and
Special Applications functions in this section. This allows you to
specify what user/packet can pass your router’s NAT.
3.5 Firewall The Firewall section allows you to configure Access Control,
Hacker Prevention and DMZ.
Select one of the above five General Setup selections and proceed to the manual’s relevant sub-
section
