1
Chapter 1 Introduction
Congratulations on purchasing PLANET XRT-401D. This Broadband Router is a cost-effective IP
Sharing Router that enables multiple users to share the Internet through an ADSL or cable
modem. Simply configure your Internet connection settings in XRT-401D and plug your PC to the
LAN port and you're ready to share files and access the Internet. As your network grows, you can
connect another hub or switch to the router’s LAN ports, allowing you to easily expand your
network. XRT-401D provides a total solution for the Small and Medium-sized Business (SMB)
and the Small Office/Home Office (SOHO) markets, giving you an instant network today, and the
flexibility to handle tomorrow's expansion and speed.
1.1 Features
·
High Internet Access throughput
· Allow multiple users to share a single Internet line
· Supports up to 253 users
·
Internet Access via Cable or xDSL modem
· Access Private LAN Servers from the Public Network
· Equipped with four LAN ports (10/100M) and one WAN port (10/100M)
· Support DHCP (Server/Client) for easy setup
· Support advance features such as: Special Applications, DMZ, Virtual Servers, Access
Control, and Firewall mode.
· Allow you to monitor the router’s status such as: DHCP Client Log, Security Log and
Device/Connection Status
· Easy to use Web-based GUI for configuration and management purposes
·
Remote Management allows configuration and upgrades from a remote site (over the
Internet)
1.2 Minimum Requirements
·
One External xDSL (ADSL) or Cable modem with an Ethernet port (RJ-45)
· Network Interface Card (NIC) for each Personal Computer (PC)
·
PCs with a Web-Browser (Internet Explorer 4.0 or higher, or Netscape Navigator 4.7 or
higher)
1.3 Package Contents
· One XRT-401D unit
·
One Quick Installation Guide
· One User Manual CD
· One Power Adapter
?
Note
The WAN “idle timeout” auto-
disconnect function may not work due to abnormal
activities of some network application software;
computer virus or hacker attacks
from the Internet. For example, some software sends network packets to the
Internet in the background, even when you are not using the Internet. So please
turn off your compu
ter when you are not using it. This function also may not work
with some ISP. So please make sure this function can work properly when you use
this function in the first time, especially when your ISP charge you by time used.
