3.5.4 DMZ

If you have a local client PC that cannot run an Internet application (e.g. Games) properly from

behind the NAT firewall, then you can open the client up to unrestricted two-way Internet access

by defining a DMZ Host. The DMZ function allows you to re-direct all packets going to your WAN

port IP address to a particular IP address in your LAN. The difference between the virtual server

and the DMZ function is that the virtual server re-directs a particular service/Internet application

(e.g. FTP, websites) to a particular LAN client/server, whereas DMZ re-directs all packets

(regardless of services) going to your WAN IP address to a particular LAN client/server.

Parameters Description

Enable DMZ Enable/disable DMZ

Note: If there is a conflict between the Virtual Server and the

DMZ setting, then Virtual Server function will have priority over

the DMZ function.

Public IP Address The IP address of the WAN port or any other Public IP

addresses given to you by your ISP

Client PC IP Address Input the IP address of a particular host in your LAN that will

receive all the packets originally going to the WAN port/Public IP

address above

Note: You need to give your LAN PC clients a fixed/static IP

address for DMZ to work properly.

You can now configure other advance sections or start using the router (with the advance settings

in place)
