11.1 Storage Report
In Record Æ Service , it contains the 8 different services as the same as
the record in Storage Report . It shows the status of storage space and
flow report. The Storage Report is displayed in
, , ,
.
Step1. Hard Disk Utilization：The 8 services are record in different colors .
When the mouse point to the colors , it will show the service name and the
usage space .
The hard disk utilization
Step2. Today’s Utilization , it is displayed in
.
Ordinate：The service flow , its unit is Mbytes.
Horizontal ordinate：The service name .
The percentage of the service record in hard disk utilization .
２０１
