Multi-Homing Security Gateway User’s Manual
Network Connection Transparent mode (WAN to DMZ), NAT, Multi-NAT
Routing Mode Static Route, RIPv2
Concurrent Sessions 110,000
New session / second 10,000
Email Capacity per Day 120,000
Firewall Throughout 100Mbps
3DES Throughput 17Mbps
Firewall Policy-based firewall rule with schedule, NAT/NAPT, SPI firewall
VPN Tunnels 100/200
VPN Function PPTP server and client, IPSec
DES, 3DES and AES encrypting
SHA-1 / MD5 authentication algorithm
Remote access VPN (Client-to-Site) and Site to Site VPN
VPN Trunk
Content Filtering URL Blocking
Blocks Popup, Java Applet, cookies and Active X
P2P Application Blocking
Instant Message Blocking
Download Blocking
IDP Anti-Virus for HTTP, FTP, P2P, IM, NetBIOS
Automatic or manual update virus and signature database
Anomaly: Syn Flood, UDP Flood, ICMP Flood and more.
Pre-defined : Backdoor, DDoS, DoS, Exploit, NetBIOS and Spyware.
Custom: User defined based on TCP, UDP, ICMP or IP protocol.
Scanning Mail Settings The allowed size of scanned mail: 10 ~ 512Kbytes
Anti-Virus Email attachment virus scanning by SMTP, POP3
Inbound scanning for internal and external Mail Server
Action of infected mail: Delete, Deliver to the recipient, forward to an account
Automatic or manual update virus database
Anti-Spam Inbound scanning for external and internal Mail Server
Support Spam Fingerprint, Bayesian filtering, checking sender account and IP
to filter the spam mail
Black list and white list support auto training system
Action of spam mail : Delete, Deliver to the recipient, forward to an account
QoS Policy-based bandwidth management
Guarantee and maximum bandwidth with 3 priority levels
Classify traffics based on IP, IP subnet, TCP/UDP port
User Authentication Built-in user database with up to 200 entries
Support local database, RADIUS and POP3 authentication
Logs Log and alarm for event and traffic
Log can be saved from web, sent by e-mail or sent to syslog server
Accounting Report Record inbound and outbound traffic’s utilization by Source IP, Destination IP
and Service
Statistics Traffic statistics for WAN interface and policies
Graphic display
Others Dynamic DNS, NTP, DHCP server, Virtual server,
- 4 -
