Multi-Homing Security Gateway User’s Manual

to be configured from a user on the Internet. Keep in mind that the device always requires a username and

password to enter the WebUI.

3.3 Policy Object

The Policy Object is the pre-setting item for Policy editing. The administrator can configure all necessary

items here before he wants to configure Multi-Homing Security Gateway Policy. The contents include

Address, Service, Schedule, QoS, Authentication, Content Blocking, Virtual server and VPN.

3.3.1 Address

The Multi-Homing Security Gateway allows the Administrator to set addresses of the LAN network, LAN

network group, WAN network, WAN group, DMZ network and DMZ group.

What is the Address Table?

An IP address in the Address Table can be an address of a computer or a sub network. The Administrator can

assign an easily recognized name to an IP address. Based on the network it belongs to, an IP address can be

an LAN IP address, WAN IP address and DMZ IP address. If the Administrator needs to create a control

policy for packets of different IP addresses, he can first add a new group in the LAN Network Group or the

WAN Network Group and assign those IP addresses into the newly created group. Using group addresses

can greatly simplify the process of building control policies.

How to use Address Table

With easily recognized names of IP addresses and names of address groups shown in the address table, the

Administrator can use these names as the source address or destination address of control policies. The

address table should be built before creating control policies, so that the Administrator can pick the names of

correct IP addresses from the address table when setting up control policies.

3.3.1.1 LAN

Entering the LAN window

Step 1. Click LAN under the Address menu to enter the LAN window. The current setting information

such as the name of the LAN network, IP and Netmask addresses will show on the screen.

- 40 -
