Multi-Homing Security Gateway User’s Manual

 From Source: Specify the VPN source to LAN or DMZ site.

 From Source Subnet / Mask: Specify the source’s LAN network subnet and Mask.

 To Destination:

- To Destination Subnet / Mask: Specify the destination LAN network subnet and

Mask.

- Remote Client: Select Remote Client if there is only one user and dials up to Internet

with PPPoE or cable modem.

 Tunnel:

- Add VPN tunnel: Select the VPN tunnel you want to add in Available Tunnel, and

click the Add>> button to add them to the Select Tunnel.

- Remove VPN tunnel: Select the VPN tunnel you want to remove in Select Tunnel,

and click the Remove>> button to remove them to the Available Tunnel.

 Keep Alive IP: Specify Remote Gateway’s LAN IP address to keep alive the VPN tunnel

 Show remote Network Neighborhood: Select to show the remote Network Neighborhood.

Modifying a Trunk

Step 1. Select VPN→Trunk.

Step 2. In the Trunk window, find the Trunk that you want to modify and click Modify.

Step 3. Enter appropriate settings.

Removing Trunk

Step 1. Select VPN→Trunk.

Step 2. In the Trunk window, find the Trunk that you want to remove and click Remove.

- 99 -
