Planet ISW-800M [6/57] Product specification
![Planet ISW-800M [6/57] Product specification](/views2/1071782/page6/bg6.png)
▫ CSMA/CD Protocol
▫ RJ-45 Port support auto MDI/MDI-X function
▫ 2K MAC address table
▫ 1Mbit memory buffer
▫ 2.0Gbps back-plane
▫ Wide-range redundant power design
▫ Store and forward switch architecture
▫ DIN rail and 3-way wall mount design
Industrial Conformance
▫ 12~48V DC, redundant power with polarity reverse protect function
▫ 0 to 60 Degree C operation temperature
▫ IP-30 Aluminum case
▫ Relay alarm for port breakdown, power failure
▫ FCC Class A, CE compatibility
▫ Free fall, Shock and Vibration Stability
Switching Feature
▫ Ring function data redundant, 300ms data recovery
▫ 802.1q Tagged VLAN/Port-based VLAN
▫ IEEE 802.1p class of service, 4 priority queues
▫ IGMP v1 and Query mode
▫ 802.1d STP/802.1w Rapid STP
▫ Ingress/Egress bandwidth control
System
▫ Web/SNMP management
▫ System event log support
▫ Configuration backup/restore
▫ E-mail event alert
▫ IP security for illegal access prevention
▫ TFTP firmware upgrade
▫ Port mirror transmission monitoring
1.4 Product Specification
Model ISW-800M
Hardware
Standard IEEE 802.3af, IEEE 802.3, IEEE802.3u, 10/100Base-TX
10/100Mbps TP 8
Protocol CSMA/CD
Switching Architecture Store and forward
Transfer Rate 144,880 pps for Ethernet port and 1448,800 pps for Fast Ethernet port
