Planet ISW-500 [7/15] Led indications

2.1.3 LED Indications

LED Status Meaning

Green

When the industrial switch has power input s the LED

will light on

Power

Off No any power inputs

Green Power on

Power 1

Off No power inputs

Green Power on

Power 2

Off No power inputs

Green The port is linking with its link partner

Blinks

The port is transmitting or receiving packets from the TX

device.

LNK/ACT

(port 7&8 of ISW-800,

port 5 of ISW-500)

Off No device attached

Orange The port is operating in full-duplex mode.

Blinks Collision of Packets occurs in the port.

FDX/COL

(port 7&8 of ISW-800,

port 5 of ISW-500)

Off The port in half-duplex mode or no device attached

Orange The port is operating in full-duplex mode.

Blinking

(Orange)

Collision of Packets occurs.

Off The port is in half-duplex mode or no device is attached.

Green A network device is detected.

Blinking

(Green)

The port is transmitting or receiving packets from the TX

device.

LED Indicator

(port 1 ~ 6 of ISW-800,

port 1 ~ 4 of ISW-500)

Off No device is attached.
