![SilverStone SST-ST1200 [11/12] En st1200 manual 11](/img/pdf.png)
SilverStone SST-ST1200 [11/12] En st1200 manual 11
![SilverStone SST-ST1200 [11/12] En st1200 manual 11](/views2/1720138/page11/bgb.png)
EPS 12V 8PIN Connector #1 & #2
18AWG wire
Y
ellow
Signal Pin
5
Pin
1
Signal
COM
18AWG wire
Black
8PIN PCI Express Connector #1
18AWG wire
Y
ellow/Blue stripe
Y
ellow/Blue stripe
Y
ellow/Blue stripe
Black sense1
Signal
+12V3
+12V3
+12V3
Pin
1
2
3
4
Pin
5
6
7
8
Signal
COM
COM
COM
COMCOM
18AWG wire
Black
Black
Black
Black
8PIN PCI Express Connector #2
18AWG wire
Y
ellow/Blue stripe
Y
ellow/Blue stripe
Y
ellow/Blue stripe
Black sense1
Signal
+12V4
+12V4
+12V4
Pin
1
2
3
4
Pin
5
6
7
8
Signal
COM
COM
COM
COMCOM
18AWG wire
Black
Black
Black
Black
18AWG wire
Black
Black
Signal
+12V2
+12V2
Pin
1
2
Pin
3
4
Signal
GND
GND
18AWG wire
Yellow
Yellow
ATX 12V 4PIN (4+4PIN EPS 12V in split mode)
