![SilverStone SST-ST1200 [8/12] En st1200 manual 08](/views2/1720138/page8/bg8.png)
5.3 Altitude
6. SAFETY
6-1. Underwriters Laboratory (UL) recognition.
The power supply designed to meet UL
6-2. The power supply must bear the German Bauart Mark from TUV
Operating
Storage
10,000FT max
50,000FT max
4-2. Hold up time
When the power loss its input power, it shall maintain 17ms in regulation limit at normal
input voltage. (AC:115V/60Hz or 230V/50Hz)
5. ENVIRONMENT
5-1. Operation
0 to 40
10 to 90%, non-condensing
Temperature
Relative Humidity
5-2. Shipping and Storage
Temperature
Relative Humidity
-20 to 60
5 to 95%, non-condensing
7. ELECTROMAGNETIC COMPATIBILITY (EMC)
7-1. IEC 1000-4-2 ESD LEVEL X20KV4.
