Si10-417_C Troubleshooting by Error Code
Service Diagnosis 161
6.20 Incomplete Setting for Hose Length
Remote
Controller
Display
UA
Method of
Malfunction
Detection
This fault occurs when the humidification hose length is
not stored in the EEPROMs of the indoor unit and the
outdoor unit.
(Hose length is not stored at initial power on.)
Malfunction
Decision
Conditions
When the humidification hose length is not stored in
EEPROMs of the indoor unit and the outdoor unit.
Supposed
Causes
Hose length is not set.
Hose length is erased by replacement of the indoor
unit PCB and the outdoor unit PCB.
(When both the indoor unit PCB and the outdoor unit
PCB are replaced simultaneously, the set value is
erased.)
Trouble-
shooting
Has the hose length
been set?
NO
Set the hose length
with the remote
controller.
Caution
Be sure to turn off the power switch before connecting or
disconnecting connectors, or parts may be damaged.
YES
(R13921)
To other UA fault
diagnosis
Check the preset hose length
with the remote controller.
