Si10-417_C Troubleshooting with LED
Service Diagnosis 5
1. Troubleshooting with LED
1.1 Indoor Unit
1.1.1 Operation Lamp
The operation lamp (or the multi-colored indicator lamp)
blinks when any of the following errors is detected.
1. When a protection device of the indoor or outdoor
unit is activated, or when the thermistor malfunctions.
2. When a signal transmission error occurs between the
indoor and outdoor units.
In either case, conduct the diagnostic procedure.
Wall Mounted Type
Wall mounted type models have a display on the lower
right side.
The following illustrations are examples.
ON
OFF
Operation lamp (green)
Operation lamp (green)
