Si10-417_C
Contents 1
Service Diagnosis
SPLIT & MULTI
1. Troubleshooting with LED............5
1.1 Indoor Unit ..................................... 5
1.2 Outdoor Unit ................................ 10
2. Troubleshooting by
Symptoms..................................11
2.1 Air conditioner does not run......... 11
2.2 Air conditioner runs but does not
cool (heat) the room. ................... 14
2.3 When operation starts, safety
breaker works. ............................. 16
2.4 Air conditioner makes big noise
and vibration. ............................... 19
2.5 Air is not humidified enough.
(for humidifying type unit) ............ 20
3. Service Check Function.............22
3.1 Check Method 1 .......................... 22
3.2 Check Method 2 .......................... 33
3.3 ARC447A1, A2, A3...................... 44
4. List of Applicable Models ...........45
4.1 Indoor Unit ................................... 45
4.2 Outdoor Unit ................................ 66
5. Error Codes and Description .....81
5.1 Indoor Unit ................................... 81
5.2 Outdoor Unit ................................ 84
6. Troubleshooting by Error
Code ..........................................94
6.1 Indoor Unit PCB Abnormality....... 94
6.2 Drain Water Level or Related
Abnormality.................................. 96
6.3 Freeze-up Protection Control or
Heating Peak-cut Control ............ 99
6.4 Fan Motor or Related
Abnormality................................ 103
