Quick heating function can be set within 20 J Jseconds after cooking zone is switched on iAnd temperature level Is adjusted Selecting Quick heating function _ i x H 1 2 Touch CD key to turn on thehob Select thedesiredcooking zone by touching the Cooking Zone Selection keys 3 Adjust the desired temperature level by touching the adjustment area or by sliding your finger across the area 4 Touch the key The cooking zone you have selected will operate at high power for a certain period of time see following table 3 lights and the set temperature value will appear on the cooking zone display respectively 5 Once the Quick heating period is over the cooking zone switches to the set temperature level and only the selected temperature value is displayed Table Quick Heating Operation Times Temperature level Operation time limit second 0 1 L 2 2 3 3 4 4 5 5 6 10 20 30 40 47 56 65 75 85 85 25 x 9 7 7 8 8 9 9 35 35 45 45 10 W Turning off Quick heating function Touch W key to turn off the Quick heating function whenever you want Cleaning lock The cleaning lock prevents operation of all keys on the control panel for 20 seconds to allow the user to make a short cleaning while the hob is in use Activating the cleaning lock 1 When the hob is in On mode press and hold key until a single signal sound is heard Cleaning lock light will illuminate and the clock display of the hob will start to count down from 20 None of the keys on the control panel will be functional throughout this period except D key Deactivating the cleaning lock You do not have to press any key to deactivate the cleaning lock The hob will give an audio signal after 20 seconds keylock light will turn off and the cleaning lock is automatically deactivated Child Lock When the hob Is In Standby mode you can protect the hob with child lock to prevent children from turning on the cooking zones Child Lock can be activated or deactivated in Standby mode only Activating the Child Lock 1 When the hob is in Standby model press and hold 0 key until two signal sounds are heard The Child Lock will be activated and the light of the 0 key will turn off _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Bf any key Is pressed when the Child ock Is active the light of the 0 key lashes Deactivating the Child Lock 1 When the Child Lock is activated press and hold 0 key until a single signal sound is heard 18 EN
