Cordless rotary hammer
INTENDED USE
•
This tool is intended for hammer drilling in concrete, brick
and stone; for drilling in wood, metal and plastic as well as for
screwdriving (specifi c accessories should be used)
•
The hammering system in this tool outperforms any tradi-
tional ratcheting drill when drilling in concrete
•
This tool is designed for use in combination with all standard
SDS+ accessories
TECHNICAL SPECIFICATIONS 1
PRODUCT ELEMENTS 2
1 On/Off switch
2 Switch for changing direction of rotation
3 Switch for selecting operating mode
4 Locking sleeve
SAFETY
WARNING! Read all instructions. Failure to follow all in-
structions listed below may result in electric shock, fi re and/
or serious injury.
• Ensure the switch is in the off position before inserting
battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.
• Recharge only with the charger specifi ed by the manufac-
turer. A charger that is suitable for one type of battery pack may
create a risk of fi re when used with another battery pack.
• Use power tools only with specifi cally designated battery
packs. Use of any other battery packs may create a risk of
injury and fi re.
• Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before you
start working
• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the charger (charg-
ers with a rating of 230V or 240V can also be connected
to a 220V supply)
• In case of electrical or mechanical malfunction, immediately
switch off the tool or unplug charger from power source
• SBM Group can assure fl awless functioning of the tool
only when original accessories are used
• Use only accessories with an allowable speed matching
at least the highest no-load speed of the tool
• This tool should not be used by people under the age
of 16 years
• Be careful not to drill or drive into areas where electrical
wires may be contacted
• Ensure that switch (2) is in the middle (locking) position
before making any adjustments or changing accessories
as well as when carrying or storing the tool
• Do not touch the contacts in the charger
• Do not expose tool/charger/battery to rain
• Never charge battery outdoors
• Store tool/charger/battery in locations where tempera-
ture will not exceed 40° C or drop below 0° C
• Batteries will explode in fi re, so do not burn battery for
any reason
• When damaged, and under extreme usage and tem-
perature conditions, batteries may start to leak
- if liquid comes into contact with the skin, wash quickly
with soap and water, then with lemon juice or vinegar
- if liquid gets into the eyes, fl ush eyes with clean water
for a minimum of 10 minutes and seek immediately medi-
cal attention
• When battery is not in tool or charger, it should be kept
away from metal objects such as nails, screws, keys etc. to
prevent short-circuit
• Do not use charger when damaged; take it to one of
the offi cially registered SBM Group Service Stations for a
safety check
• Do not use battery when damaged; it should be replaced
immediately
• Do not disassemble charger or battery
• Do not attempt to recharge non-rechargeable batteries
with the charger
• Normally when starting to charge the discharged battery,
red and green LEDs of the battery charger are on. When the
battery is fully charged only green LED is on. If no LEDs are
on while the charger is on, do not use the battery and the
charger and take them to the service center.
• When using your tool continuously, the batteries in your
battery pack will become hot. You should let a hot battery
pack cool down for approximately 30 minutes before at-
tempting to recharge.
• In case of long storage, store the battery in fully charged
condition.
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of the charger to the earth terminal of the plug
• If for any reason the old plug is cut off the cord of the charger,
it must be disposed of safely and not left unattended
To ensure longer service life and proper perfor-
mance of the battery, take the following actions
when you start using new battery:
1. Use the new battery, without recharging it, till its com-
plete discharge.
2. Then charge the battery for 3-5 hours.
3. Repeat abovementioned actions (1 and 2) 3-5 times to
reach the nominal battery capacity.
MAINTENANCE
Regularly clean the machine housing with a soft cloth, pref-
erably after each use. Keep the ventilation slots free from
dust and dirt.If the dirt does not come off use a soft cloth
moistened with soapy water. Never use solvents such as
petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
The machine requires no additional lubrication.
Should a fault occur, e.g. after wear of a part, please con-
tact your local SBM Group dealer.
ENVIRONMENT
In order to prevent the machine from damage during trans-
port, it is delivered in a sturdy packaging. Most of the pack-
aging materials can be recycled. Take these materials to
the appropriate recycling locations. Take your unwanted
machines to your local SBM Group dealer. Here they will
be disposed of in an environmentally safe way.
Li-Ion batteries can be recycled. Deliver them to a disposal
site for chemical waste so that they can be recycled or dis-
posed of in an environmentally friendly manner.
Make sure that the machine is not live when
carrying out maintenance work on the motor.
