New2001
36
6
MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
GPS
Alarm Area2
GPS Set
Altitude/DistanceUnits
Speed Units
GPS Out
Alarm Area1
In this item, set the GPS options.
Limited, Extended or Both
m or ft/ml
km/h, mph or knots
OFF or ON
0’05”/0.08’~0’15”/0.25’~
59’59”/59.99’
☞
Continues on the next page.
GPS Indicator
GPS Select
Manual Position
OFF or ON
OFF, Internal GPS,
External GPS or Manual
Power Save (Internal GPS)
OFF, 1min, 2min, 4min, 8min or Auto
Position Format
ddd˚mm.mm' or ddd˚mm'ss"
NOTE: The default settings, shown below, are for the USA version.
The default settings may differ, depending on the version.
DESCRIPTIONSRANGE OR VALUE (Default is shown in bold)
Selects a GPS receiver that the trans-
ceiver receives its position data from.
Selects the internal GPS receiver power
save function.
Manually enters your current position.
Turns the GPS indicator ON or OFF.
Selects position format to display the po-
sition.
Selects units to display the distance and
elevation.
Selects units to display the speed.
Enters the GPS alarm active range.
Selects the GPS alarm active range.
Selects the GPS information from the in-
ternal GPS receiver that is output to the
[DATA]jack.
