MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
CI-V
CI-V Address
CI-V Baud Rate
CI-V Transceive
01~84~DF
300, 1200, 4800, 9600, 19200 or Auto
OFF or ON
In this item, set other options.
Function (Continued)
NOTE: The default settings, shown below, are for the USA version.
The default settings may differ, depending on the version.
DESCRIPTIONSRANGE OR VALUE (Default is shown in bold)
Sets the transceiver's unique CI-V hexa-
decimal address code.
Sets the CI-V code transfer speed.
Turns the CI-V Transceive function ON
or OFF.
Selects the transceiver backlight option.
Selects the backlight ON time period.
Selects the LCD backlight brightness
level
Sets the contrast level of the LCD.
TurnstheTX/RXindicatorONorOFF.
Display
Backlight
LCD Dimmer
LCD Contrast
Busy LED
OFF, ON, Auto or Auto (DC IN:ON)
In this item, set the Display options.
Bright or Dark
1~8~16
OFF or ON
Backlight Timer 5sec or 10sec
DESCRIPTIONSRANGE OR VALUE (Default is shown in bold)
☞
Continued on the next page.
RX Call Sign OFF, Auto or Auto (RX Hold)
Selects the call sign display option when
receiving a call.
