MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
NOTE: The default settings, shown below, are for the USA version.
The default settings may differ, depending on the version.
Sets the beep output level.
Selects whether or not the beep output
levelcanbeadjustedbythe[VOL]control.
Turns the confirmation beep tones when
key is pushed, ON or OFF.
Turns the scan stop beep ON or OFF.
Turns the standby beep function in the
DV mode ON or OFF.
Selects the audio output capability during
a sweep by the Band Scope function.
Selects if the time data is automatically
corrected by a received GPS sentence.
Sets the current date and time.
Enters the time difference between UTC
and the local time.
Turns the Auto power OFF function ON
or OFF.
Sounds
Beep Level
Beep/VolLevelLink
Key-Touch Beep
Scan Stop Beep
Scope AF Output
Standby Beep
0~3~9
In this item, set the Sound options.
OFF or ON
OFF or ON
OFF or ON
OFF or ON
OFF, ON or ON (to me:High Tone)
DESCRIPTIONSRANGE OR VALUE (Default is shown in bold)
Time Set
Date/Time
GPS Time Correct
UTC Offset
Auto Power OFF
In this item, set the Time options.
OFF or Auto
–14:00~±0:00~+14:00
OFF, 30min, 60min, 90min or 120min
DESCRIPTIONSRANGE OR VALUE (Default is shown in bold)
☞
Continued on the next page.
