Icom IC-T70E [5/96] Supplied accessories
![Icom IC-T70A [5/96] Supplied accessories](/views2/1074089/page5/bg5.png)
New2001
iv
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom
Incorporated (Japan) in Japan, the United States, the United King-
dom, Germany, France, Spain, Russia and/or other countries.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Microsoft, Windows and Windows Vista are registered trademarks of
Microsoft Corporation in the United States and/or other countries.
SUPPLIED ACCESSORIES
The following accessories are supplied with the transceiver.
q
Hand strap ��������������������������������������������������������������������� 1
w
Antenna �������������������������������������������������������������������������� 1
e
Battery pack (BP-264)* �������������������������������������������������� 1
r
Belt clip* ��������������������������������������������������������������������������1
t
Battery charger (BC-167SA/SD/SV)* ����������������������������� 1
* Not supplied, or the shape is different, depending on the transceiver
version.
t
eq
r
w
