!1 SUB CHANNEL READOUT
Displays Channel 16 during a priority scan, Dualwatch
or Tri-watch. (p. 16)
Displays the Set mode item while in the Set mode. (p. 17)
Displays the volume level while in the volume adjust-
ment mode. (p. 10)
Displays the squelch level while in the squelch adjust-
ment mode. (p. 10)
!2 SQUELCH LEVEL ICON
Displays the squelch level.
SQL blinks while adjusting the squelch level. (p. 10)
!3 VOLUME LEVEL ICON
Displays the volume level.
The bars repeatedly appear in ascending order when
the Volume Loud function is turned ON. (p. 12)
The bars blink while the Volume Mute function is turned
ON. (p. 12)
VO
L blinks while adjusting the volume level. (p. 10)
!4 CHANNEL NUMBER READOUT
Displays the selected operating channel number.
In the Set mode, displays the selected setting or value.
(p. 17)
!5 CHANNEL GROUP ICON (p. 9)
appears when USA; appears when International;
appears when Canadian channel group is selected.
!6 WEATHER CHANNEL/WEATHER ALERT ICONS (p. 9)
WX appears when the weather channel group is se-
lected.
WX ALT” appears while the Weather Alert function is
turned ON; blinks when the alert tone is received.
!7 LOW POWER ICON (p. 11)
LOW appears when low power is selected.
LOW blinks when switching to the low power mode is
forced because of a high temperature error or low volt-
age.
7
3
PANEL DESCRIPTION
