Icom IC-M24 [26/40] Set mode items
![Icom IC-M24 [26/40] Set mode items](/views2/1074258/page26/bg1a.png)
18
7
SET MODE
■ Set mode items
D Beep Tone function “bP”
Turn the key touch beep sound ON or OFF.
• OFF : For silent operation.
• ON : A beep sounds.
D Weather Alert function “AL”
A NOAA broadcast station transmits a weather alert tone be-
fore any important weather announcements. When the func-
tion is turned ON and the transceiver detects a weather alert
tone, the “WX ALT” icon blinks and a beep sounds. The blink-
ing stops when an operation is performed.
The currently selected weather channel is checked while the
Power Save function is activated, or during a scan.
• “ALT” appears when the function is set to ON.
D Priority Scan function “Pr”
The transceiver has 2 scan types— normal (OFF) and pri-
ority (ON) scan. A normal scan searches all TAG channels
in the selected channel group. A priority scan
sequentially
searches all TAG channels while monitoring Channel 16.
D Scan resume timer “St”
The Scan resume timer can be set as a pause (OFF) or
timer scan (ON).
• OFF : When a signal is detected, the scan pauses on the channel
until the signal disappears, and then resumes.
• ON : When a signal is detected, the scan pauses on the channel
for 5 seconds, and then resumes.
Bee
p
tone ON
(
default
)
Bee
p
tone OFF
Push
Weather Alert function
OFF (default)
Weather Alert function
ON
Push
Normal scan (default) Priority scan
Push
Scan resume timer OFF Scan resume timer ON
Push
