28
SPECIFICATIONS AND OPTIONS
11
■ Specifi cations
D GENERAL
• Frequency coverage : Transmit 156.025–157.425 MHz
Receive 156.050–163.275 MHz
• Mode : FM (16K0G3E)
• Power supply requirement : BP-266 only
• Current drain (approximately) : TX (5 W/1.0 W) 2.3 A/0.9 A
Max. audio
0.35 A typical
Power save 8 mA typical
• Frequency stability : ±10 ppm
• Operating temperature range : –20°C to +60°C; –4°F to +140°F
• Dimensions : 58.5 (W) × 128.5(H) × 34.5(D) mm
(projections not included) 2
5
⁄16(W) × 5
19
⁄32(H) × 1
11
⁄32(D) inch
• Weight : Approximately 260 g; 9.2 oz
(including battery pack, antenna and belt clip)
D TRANSMITTER
• Output power : 5 W (approximately; High) and 1 W (Low)
• Modulation system : Variable reactance frequency modulation
• Maximum frequency deviation : ±5 kHz
• Adjacent channel power : 70 dB
• Spurious emissions : –68 dBc typical
• Residual modulation : 40 dB
• Audio frequency response : +1 dB to –3 dB of 6 dB oct. from 300–3000 Hz
D RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequency : 1st 21.7 MHz, 2nd 450 kHz
• Sensitivity (12 dB SINAD) : 0.25 µV typical
• Squelch sensitivity : 0.35 µV typical (at threshold)
• Intermodulation : 70 dB typical
• Spurious response : 70 dB typical
• Adjacent channel selectivity : 70 dB typical
• Audio output impedance : 8 Ω
• Audio output power : 0.6 W typical (at 10% distortion)
All stated specifi cations are subject to change without notice or obligation.
■ Options
D BATTERY PACK
• BP-266 Li-ion BATTERY PACK
Voltage/Capacity : 3.7 V/1500 mAh (minimum), 1590 mAh (typical)
D CHARGERS
• BC-199S AC ADAPTER
For regular charging of the battery pack.
Charging time : Approximately 8.5 hours
• BC-119N DESKTOP CHARGER + AD-123 CHARGER ADAPTER
+ BC-145S AC ADAPTER
For rapid charging of the battery pack. The AC adapter, BC-145S, is not sup-
plied with some versions.
Charging time : Approximately 2.5 hours
•
BC-121N MULTI-CHARGER + AD-123 CHARGER ADAPTER + BC-157S AC ADAPTER
For simultaneously rapid charging up to six battery packs (six AD-123s are
required). An AC adapter must be separately purchased.
Charging time : Approximately 2.5 hours
D OTHER OPTIONS
• FA-SC58V ANTENNA
• MB-124 BELT CLIP
• CP-24 CIGARETTE LIGHTER CABLE
• CP-23L CIGARETTE LIGHTER CABLE
For BC-119N
• OPC-515L DC POWER CABLE
For BC-119N
Approved Icom optional equipment is designed for optimal performance when
used with an Icom transceiver. Icom is not responsible for the destruction or
damage to an Icom transceiver in the event the Icom transceiver is used with
equipment that is not manufactured or approved by Icom.
Some options may not be available in some countries. Please ask your dealer
for details.
