Icom IC-T7H [15/36] Setting tuning steps

BASIC OPERATION

■

Setting tuning steps

This transceiver has 8 tuning steps (VHF and UHF bands

have independent settings) as follows:

• 5 kHz • 10 kHz • 12.5 kHz • 15 kHz

• 20 kHz • 25 kHz • 30 kHz • 50 kHz

➀ Push [VFO] to select VFO mode.

➁ Push [BAND] to select the VHF or UHF band.

➂ Push [(H/L)SET] for 1 sec. to enter set mode.

➃ Push [TONE] or [H/L] several times until “TS” appears.

➄ Rotate [DIAL] to select the desired tuning step.

➅ Push [(VFO)CLR] to exit set mode.

For convenience, select a tuning step that matches the fre-

quency intervals of repeaters in your area.

[DISPLAY EXAMPLE]

15 kHz tuning step 25 kHz tuning step

USING

SET MODE

D Via the keypad

(other band directly)

➀ Push [VFO] to select VFO

mode.

➁ Push 6 digit keys, starting

from the 100 MHz digit.

• The operating band changes

automatically.

• It’s not necessary to input the

decimal point.

D Other methods

➥ VIA THE DIAL: Rotate [DIAL] to change the frequency ac-

cording to the set tuning steps.

➥ USING THE MHz STEP: Push [

(VFO)MHz] for 1 sec., then

rotate [DIAL] to change the frequency in one MHz steps.
