![Icom IC-T7H [33/36] Specifications](/views2/1074443/page33/bg21.png)
29
SPECIFICATIONS
8
VHF UHF
GENERAL
Frequency
coverage
(MHz)
U.S.A.
Tx: 144–148
Rx: 118–174*
1
Tx: 430–450*
2
Rx: 400–470*
2
Europe, U.K.
144–146 430–440
430–440
Guaranteed ranges are:
*
1
144–148
*
2
440–450
*
3
430–440
Mode FM (F3E)
±5 ppm
(0°C to +50°C; +32°F to +122°F)
Tuning steps (kHz)
5, 10, 12.5, 15, 20, 25, 30 or 50
Antenna connector BNC (50 Ω)
Usable battery pack/case
Tx: 430–440
Rx: 400–470*
3
Current drain
(at 13.5 V, typ.)
See options on page 28.
Tx: 144–148
Rx: 118–174*
1
Asia
Tx: 144–148
Rx: 136–174*
1
Italy
Frequency stability
External DC power
4.5 to 16 V DC (negative ground)
190 mA
1.6 A1.6 AHigh
Tx
180 mARated audio
Rx
Power saved
(at 9.6 V)
Low 600 mA 700 mA
16 mA (average) 18 mA (average)
Weight (with BP-180)
Dimensions (with BP-180)
(projections not included)
320 g; 11.3 oz
57(W)×122(H)×29(D) mm;
2
1
⁄4(W)×4
13
⁄16(H)×1
5
⁄32(D) in
Usable temperature range
–10°C to +60°C;
(+14°F to +140°F)
VHF
TRANSMITTER
Output power*
(at 13.5 V)
6 W, 0.5 W
(selectable)
Modulation system
Variable reactance frequency
modulation
Max. freq. deviation* ±5.0 kHz
Ext. microphone jack
2.5 mm (
1
⁄10 in) 3-conductor/2 kΩ
RECEIVER
Receive system
Double conversion superheterodyne
Intermediate frequencies
Sensitivity*
(12 dB SINAD)
Less than 0.18 µV
Squelch sensitivity Less than 0.18 µV
Selectivity
More than 15 kHz/–9 dB
Less than 30 kHz/–50 dB
Spurious and image
rejection ratio*
More than 60 dB
Audio output power*
(at 13.5 V)
More than 500 mW
(at 10% distortion with an 8 Ω load)
Ext. microphone jack
3.5 mm (
1
⁄8 in) 3-conductor/8 Ω
UHF
*Specifications guaranteed at a transceiver temperature of +25°C (+77°F).
All stated specifications are subject to change without
notice or obligation.
More than 50 dB at IF⁄2
More than 50 dB
1st: 45.15 MHz 2nd: 450 kHz
6 W, 0.5 W
(selectable)
